Paper Pulp Making Equipment

Product description: Our company can design the technical programs and make an offer of model ’D’ hydrapulper for the customer’s reference with their requirements.
INQUIRY

Name:Paper Pulp Making Equipment , Model D Hydrapulper

Description:

Model ’D’ Hydrapulper, hydrapurger II, drum screen, ragger and grapple make up of continuous pulping and discharging system. This system is used for processing OCC, AOCC, etc. The plastics, styrene and other light and heavy rejects can be discharged from the tub before being broken and flow through the screen plate, so the production and pulp quality are improved.

Applications:

Model ’D’ Hydrapulper is used for continuously breaking waste paper. Model ’D’ hydrapulper, hydrapurger II, drum screen, ragger and grapple make up of continuous pulping and discharging system. This system is used for processing OCC, AOCC, etc.

Specifications:

Model	Volume(m³)	Capacity(T/D)	Pulping consistency(%)	Power(KW)
D-10	10	60-80	2-5	110
D-15	15	80-120	2-5	160
D-20	20	100-160	2-5	185
D-25	20	120-200	2-5	250
D-30	30	180-250	2-5	280
D-35	35	200-320	2-5	315
D-40	40	260-370	2-5	355
D-45	45	280-400	2-5	400
D-50	50	300-450	2-5	450
D-60	60	360-520	2-5	560
D-70	70	420-600	2-5	630
