Name:Normal Rewinder Machine

Quick Detail:

Normal Rewinder is one of finishing equipment for paper machine production line, and it is used for slitting and rewinding the paper.

Specifications:

Normal Rewinder

1. Paper kinds: Cardboard paper, corrugated raw paper, cultural paper, etc.

2. Quantitative: 60-500g/㎡

3. Specification: 1092-2800mm

4. Gauge: 2200-3800mm

5. Working speed: 100-300m/min

6. Max diameter of raw paper: 1200-1800mm

7. Max diameter of finished paper: 800-1200mm

8. Drive mode: DC speed adjusting motor drive.

9. Braking mode: Magnetic powder brake or pneumatic brake.

Competitive Advantage:

Our company can design the technical programs of normal rewinder and make an offer for the customer’s reference with the requirements of customer.
